Outdoor shutters are a stylish and functional addition to any home. They offer privacy, protection, and curb appeal. However, to get the most out of your shutters, accurate measurements are key. In this article, we'll walk you through how to measure for outdoor shutters, covering everything from width and height to depth and hardware needs. By the end, you'll know exactly how to get the perfect fit for your windows.
Before you start the measuring process, it's important to understand why precise measurements are necessary. Incorrect measurements can lead to shutters that are too large or small, resulting in poor aesthetics or functionality.
For functional outdoor shutters, precision ensures they can open and close properly, while for decorative shutters, it guarantees a balanced and visually appealing look.
Measuring for outdoor shutters begins with careful inspection. This first step ensures there are no obstructions that could interfere with the shutters's installation.
Obstructions: Look for downspouts, rooflines, flagpoles, or shrubs that could prevent shutters from fitting properly or interfere with their movement.
Space Between Windows: Ensure the shutters won't collide with those on neighboring windows, especially when they open.
Window Condition: Check for issues like wood rot in the frame that might need to be addressed before installation.
Tip: If you have trees or large plants close to the window, consider their growth to avoid obstructions later.
For functional shutters, the depth of your window opening is a key measurement. The shutters should ideally fit inside the opening, with a slight clearance to allow them to swing.
From the Back of the Jamb to the Casing: Measure from the back of the window frame (side jamb) to the front of the window casing.
Clearance: For wooden shutters, allow for a 1-inch clearance for pine shutters and 1.5 inches for premium wood shutters.
Note: If your window lacks the depth to house shutters, you may need to install them outside the casing with specialized hinges.
Measuring the width of your window is crucial to determine how many shutter panels you need and their individual sizes.
Inside the Window: Measure from the inside left of the window opening to the inside right. Record the narrowest measurement from three points (top, middle, bottom).
Clearance: Deduct ¼ inch to ½ inch for proper clearance when the shutters are closed. Divide this measurement by two to find the width of each individual shutter panel.
Example: If the window width is 40 inches, subtract ½ inch, leaving 39.5 inches. Divide by 2 for 19.75-inch wide shutters.
For Shallow Openings: If the window opening is shallow, measure from the outside of the casing. The same clearance rule applies.
Tip: Windows narrower than 45 inches often use a single shutter panel that opens to one side.
Height measurements are equally important. The shutters need to cover the entire height of the window for a proper fit and functionality.
Inside the Window: Measure from the inside top of the window opening to the inside bottom.
Clearance: As with the width, subtract ¼ inch to ½ inch to allow for the shutters to move freely when closed.
For Shallow Openings: If the window is shallow, measure from the outside top of the casing to the bottom of the sill or the casing if there's no sill.
Tip: Always measure in three places (left, center, and right) to ensure accuracy.
For certain shutter styles, especially louvered shutters, a divider rail or custom louver positioning is essential. This adds strength and visual appeal, especially for taller shutters.
Standard Divider Rail: For shutters taller than 70 inches, you’ll need a divider rail at the center, or at a custom height if desired.
Shutter Styles with More Rails: For board-and-batten shutters, a third batten may be necessary for added strength, especially for shutters over 55 inches.
Aligning with Window Features: If your window has a horizontal feature (like a transom or mullion), align the divider rail with it for symmetry.
Tip: Custom divider rails give you the flexibility to achieve your desired aesthetic, but aligning them with existing window features offers a more cohesive look.
Choosing the right hardware is essential for the longevity and functionality of your shutters. Outdoor shutters are typically installed with hinges that allow them to open and close.
Shutter Hinges: Select high-quality, outdoor-rated hinges for durability. Ensure they are strong enough to support the weight of the shutters.
Shutter Dogs and Tiebacks: These are essential if you want your shutters to stay open when not in use. They add functionality and can be decorative.
Mounting: If the window frame lacks depth, you may need to use new construction shutter hinges, which are designed to mount shutters on the outside of the window.
Tip: Choosing the correct hinge and hardware for your outdoor shutters will ensure easy operation and prevent premature wear and tear.
Once you have all your measurements, it's time to do a final check. Double-check every measurement to ensure that your shutters will fit properly. Remember, even small discrepancies can lead to installation problems later.
Measure for Depth: Ensure you have at least 1 inch for pine shutters and 1.5 inches for premium wood.
Check for Obstructions: Make sure nothing will interfere with the shutters'movement.
Ensure Symmetry: If you're installing decorative shutters, verify that the width and height are symmetrical.
Accurate measurements are key to ensuring your outdoor shutters fit perfectly and function as they should. By following these steps, you can confidently measure for both functional and decorative shutters. Whether you choose traditional wood shutters or modern materials like PVC or aluminum, taking the time to measure correctly will save you time and frustration during installation. Kinghands Sunshade provides high-quality outdoor shutters and professional guidance to help ensure a perfect fit and long-lasting performance. Consider consulting their experts to verify your measurements and achieve the best results for your outdoor shutters.
A: To measure for outdoor shutters, first measure the width and height of your window. Ensure the measurements are accurate to guarantee the shutters fit well. Pay attention to the depth and consider the hardware required for installation.
A: When measuring exterior shutter width and height, measure the window's outer frame for the width and from top to bottom for the height. These dimensions ensure a precise shutter fit.
A: The best type of outdoor shutters depend on your aesthetic and functional needs. Consider materials like wood, PVC, or aluminum for durability and style.
